FDA 70N20 MOSFET N-CH 70A 200V

Product Category:MOSFET

Technology:Si

Mounting Style:Through Hole

Package/Case:TO-3PN-3

Transistor Polarity:N-Channel

Number of Channels:1 Channel

Vds - Drain-Source Breakdown Voltage:200 V

Id - Continuous Drain Current:70 A

Rds On - Drain-Source Resistance:35 mOhms

Vgs - Gate-Source Voltage:30 V

Minimum Operating Temperature:- 55 C

Maximum Operating Temperature:+ 150 C

Pd - Power Dissipation:417 W

Channel Mode:Enhancement

Configuration:Single

Height:20.1 mm

Length:16.2 mm

Series:FDA70N20

Transistor Type:1 N-Channel

Width:5 mm

Brand:ON Semiconductor / Fairchild

Fall Time:39 ns

Product Type:MOSFET

Rise Time:235 ns

Typical Turn-Off Delay Time:65 ns

Typical Turn-On Delay Time:71 ns
