The function of the controller is to protect the voltage overshoot and discharge. -
When the battery voltage is too low, the controller to stop output; after the solar panels charging, the battery will return to 12.6 v. It is a natural to output. -
12.6 v is to restore the discharge voltage. -
When the solar panels to recharge battery float charging voltage can be achieved. It will stop charging. This is called overshoot protection. -
After the battery discharge, the battery outside will flash, this is to remind the user, the configuration is not reasonable, it need to take battery connection. -
The controller normal voltage of 10.8 v to 13.7v. This two voltage fluctuation, you can be set manually. -
Color: Black, Blue -
Material: Plastic -
Max. Charge/Discharge Current: 20A -
Max. Solar Panel Input Voltage: ≤50V -
Rated Voltage: 12V / 24V Auto -
Only For off-Grid PV Solar System. -
For 20A 12V Pv System: -
240W Solar Panel -
12V Lead-acid Battery -
25V for Max input Voltage -
For 20A 24V Pv System: -
360W Solar Panel -
24V Lead-acid Battery -
50V for Max input Voltage? -
USB Output Voltage/Current: Dual 5V 2A -
No Load Loss: ≤10mA -
Temperature Compensation: -3mV/Cell/°C -
Operation Temperature: -20°C~60°C -
Item Size: 133.2x69.8x33.5mm -
Item Weight: 119g~152g
