Λεπτομέρειες
| Frequency Range: | 20 Hz – 6 MHz |
| Level / Impedance: | 1V ± 1dB /75Ω |
| Frequency Range: | 20Hz – 15KHz |
| Level Adjustment: | 0- 14dB |
| Level/Impedance/Deviation: | 775mV RMS/ 10kΩ /50 KHz |
| Level (Typical)/Impedance: |
85dBμV/75Ω |
| Level Adjustment: | 0 – 15 dB |
| RF Output (Frequency Range): | •21 – 69 ( G , H , I , L , K ) / 470 – 862 MHz |
| •14 – 78 ( M , N ) / 470 – 862 MHz | |
| •6 – SR18 (D) / 174 – 294 MHz | |
| •E5 – S20 (B) / 174 – 300 MHz | |
| •L05 – P (L) / 174 – 292 MHz | |
| •1 – 3 (D) / 48.5 – 84 MHz | |
| •E2 – E4 (B) / 47 – 68 MHz | |
| Carriers Accuracy: | ± 50kHz |
| Sound Subcarrier Frequency: | 4.5 MHz, 5.5 MHz |
| Fine Tuning Range of Video Carrier Frequency: | ±2.2 5 MHz max . by 0. 25 MHz step |
| Combining Through Loss SAT/Terr: | 5/ 3.5 dB |
| Frequency Range of RF Combining: | 5 – 2150 MHz |
| Video Frequency Response: | ± 1 dB |
| A/V Ratio: | 12 /16 dB |
| Amplitude Modulation Depth, Typical: | 81 % |
| Adjusting of Sound Modulation Depth: | ± 6 dB |
| Signal / Noise Ratio, Weighted: | ≥ 55 dB |
| Power Consumption: | 230V -50Hz – 2.5W |
| Dimensions: | 135*80*50 mm |
