Technical Characteristics
| Camera |
| Appearance |
Turret |
| Image Sensor |
5 MP CMOS image sensor |
| Signal System |
PAL/NTSC |
| Video Frame Rate |
TVI: 5 M @ 20 fps, 4 M @ 30 fps, 4 M @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps |
| Effective Pixels |
2560 (H) × 1944 (V) |
| Min. illumination |
0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Time |
1/25 (1/30) s to 1/50,000 s |
| Lens |
2.8 mm |
| Angle of view |
2.8 mm, horizontal FOV: 85°, vertical FOV: 63°, diagonal FOV:110° 3.6 mm, horizontal FOV: 80°, vertical FOV: 63°, diagonal FOV:105° |
| Lens Mount |
M12 |
| Day & Night |
Auto/Color/BW (Black and White) |
| Angle Adjustment |
Pan: 0 to 360°, Tilt: 0 to 75°, Rotation 0 to 360° |
| Material |
Metal |
| Menu |
| BLC |
Support |
| Interface |
| Video Output |
1 Analog HD output |
| General |
| Operating Conditions |
-40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing) |
| Power Supply |
12 VDC ±25% |
| Power Consumption |
Max. 4.3 W |
| Protection Level |
IP66 |
| IR Range |
Up to 20 m |
| Dimensions |
Ø 82.6 mm × 69.66 mm (Ø 3.25" × 2.74") |
| Weight |
Approx. 230 g (0.51 lb.) |
|
