ΤΡΟΦΟΔΟΤΙΚΟ SWITCHING 12V 3A-4 ΕΞΟΔΩΝ

Κωδικός Προϊόντος: 42690

Με ασφάλειες 1A ανά έξοδο.

Ρυθμιζόμενη έξοδος έως 14V για εξισορρόπηση πτώσης τάσεως λόγο μεγάλου μήκους καλωδίου

ΤΡΟΦΟΔΟΤΙΚΟ SWITCHING 12V 3A-4 ΕΞΟΔΩΝ is available for purchase in increments of 1

Διαθεσιμότητα:Άμεσα Διαθέσιμο / 1-3 Εργάσιμες

Τιμή eshop (Με ΦΠΑ) 25,50€

Λεπτομέρειες

Model:	CP1209-3A-4
OUTPUT	-Output Current Range:	3A
	-DC Output Voltage:	12V±10%
	-Wave and Noise:	120mVp-p
	-DC Output Power:	36W
	-Efficiency:	85%
	-DC Voltage Adjustable Scope:	(at full load)?0.5%
INPUT	-Voltage Range:	85~264VAC 47-63Hz
	-Input Current:	0.14A/115V, 0.07A/230V
	-Leakage Current:	<1mA/ 240VAC
	-Inrush Current:	Cold start 20A/120VAC, 40A/230VAC
PROTECTION	-Over-Load:	105%~135%, Protection type: Constant current limiting, recovers automatically after fault condition is removed
	-Over-Voltage:	105%—150% Rated Voltage, Protection type: Shut off
	-High-Temperature:	RTH3>=65°C FAN ON<=55°C, FAN OFF>=80°C Cut Off Output(5~15V)
ENVIRONMENT	-Working Temperature:	-10°C~+50°C
	-Working Humidity:	20~90%RH
	-Store Temperature:	-20°C~+85°C
	-Store Humidity:	10~95%RH
	-Temperature Co-Efficient:	±0.03%°C(0~50°C)
	-Vibration:	10~500Hz, 2G 10min./1cycle, Period for 60min, EACH AXES
SAFETY	-Withstand Voltage:	I/P-O/P: 1.5KVAC, I/P-FG: 1.5KVAC, O/P-FG: 0.5KVAC
	-Isolation Resistance:	I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC
STANDARD	-CE EMC Standard:	EN55015:2013+A1:2015, EN61547:2009 EN61000-3-2:2014, EN61000-3-33:2013
	-CE LVD Standard:	EN61347-2-13:2014+A1:2017, EB61347-1:2015
	-ROHS Standard:	IEC 62321: 2013, EPA3050B:1996, EN1122:2001, EPA3052:1996, EPA3060A, etc.
OTHER	-Dimensions:	16316347mm(LWH)
